Starting Procedure For Diagnostic Function
- Turn the ignition switch to the ACC or ON position.
- Press the MENU button.
- Select "Navigation Set Up".
- Select "Calibration".
- Select "Map Version".
- Press the joystick up two times , then down two times .
- "Diagnosis Check" is displayed on the screen.
DISPLAY ITEM DESCRIPTION
| No. | Display item | Description | ||
|---|---|---|---|---|
| 1 | REV | Indicate Reverse signal state.
|
||
| 2 | Microphone | Indicate the connection state of a microphone
|
||
| 3 | Speed(1) | Indicate the present vehicle speed by kph/mph (a maximum of 3 digits). | ||
| 4 | TNS(1) | Indicate the TNS signal state.
|
||
| 5 | GPS Antenna(1) | Indicate the connection state of a GPS antenna.
|
||
| 6 | Traffic System | Indicate the RDS-TMC system availability on the vehicle.
|
||
|
||||
