| DETECTION CONDITION |
- If 5 s or more
have elapsed with the generator output voltage 8.49 V or lower
and the battery output voltage 10 V or more
(even though the generator target output current while the engine is running is 19.5 A or more
), the PCM determines that the charging system circuit has a malfunction.
Diagnostic support note
- This is a continuous monitor (other).
- The MIL does not illuminate.
- FREEZE FRAME DATA (Mode 2)/Snapshot data is not available.
- The DTC is stored in the PCM memory.
|
