Fuel Pump Control Module Removal/Installation

  1. Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION .)
  2. Tip the rear seat back (LH). (See REAR SEAT BACK REMOVAL/INSTALLATION .)
  3. Remove in the order indicated in the table.
    Fig 1: Exhaust System Removal/Installation Replacement Components With Torque Specifications
    G09785361Courtesy of MAZDA MOTORS CORP.
  4. Install in the reverse order of removal.
