Vehicle With Emergency Call System
B1207-86: (BCM) DETECTION CONDITION AND POSSIBLE CAUSE (VEHICLE WITH EMERGENCY CALL SYSTEM)
| System malfunction location |
Error signal received from emergency call unit/telematics communication unit |
| Detection condition |
- The door-electrical supply unit (driver's side) receives the error signals from the emergency call unit/telematics communication unit.
|
| Fail-safe |
|
| Possible cause |
- DTCs are stored in the emergency call unit/telematics communication unit. (See DTC TABLE [TCU]
.)
- Malfunction in wiring harness (including connector/terminal) between emergency call unit/telematics communication unit and door-electrical supply unit (driver's side) (See
CIRCUIT INSPECTION
.) (See
CONNECTOR INSPECTION
.)
- Emergency call unit/telematics communication unit malfunction (Refer to [EMERGENCY CALL UNIT REMOVAL/INSTALLATION]
in service information.) (Refer to TELEMATICS COMMUNICATION UNIT REMOVAL/INSTALLATION
in service information.)
- Door-electrical supply unit (driver's side) malfunction (Refer to DOOR-ELECTRICAL SUPPLY UNIT REMOVAL/INSTALLATION
in service information.)
- Body control module (BCM) malfunction (Refer to BODY CONTROL MODULE (BCM) REMOVAL/INSTALLATION
in service information.)
|
| Repeatability verification procedure |
- Clear the DTC recorded in the memory. (See
CLEARING DTC
.)
|
 Courtesy of MAZDA MOTORS CORP.
|
| 1 |
Door-electrical supply unit (driver's side) |
| 2 |
Emergency call unit/telematics communication unit |
