Removal & Installation: Notes

NOTE: For removal and installation procedures, refer to appropriate illustration(s). See Figure-Figure .

NOTE: The screws and nuts for window lift are micro-encapsulated. They must be replaced or screwed in with screw locking compound. If the door foil is damaged during removal, replace foil and carefully glue on.
