Flap for fuel filler neck

WARNING: This page is about a different car, the 2013 BMW X5 M, 2012 BMW X5 M, 2011 BMW X5 M, and 2010 BMW X5 M. However, it is still accessible from the selected car via links, so may be relevant.

Area specification applies to all paint stages.

Additionally with inner panel for paint stages 2 and 3.

Fig 1: Identifying Paint Applying Areas On Fuel Filler Neck Flap (Area Specification Applies To All Paint Stages)

Courtesy of BMW OF NORTH AMERICA, INC.

Cover, air duct, bottom left or right

Vehicles up to 02 2010

Area specification applies to all paint stages.

Fig 2: Identifying Paint Applying Areas On Air Duct Cover (Area Specification Applies To All Paint Stages)

Courtesy of BMW OF NORTH AMERICA, INC.
