Main Switch (1992)

  1. In each switch position, continuity should be present between terminals No. 2 and 7 for switch illumination. SeeFigure -Figure . When switch is moved to Neutral position, continuity should be present between terminals No. 1 and 4.
  2. When switch is moved to ON position, continuity should be present between terminals No. 1, 4 and 5. Connect battery voltage to terminal No. 5 and ground terminal No. 4.
  3. Battery voltage should then be present on terminal No. 1 when main switch is moved to On position. Replace switch if it does not test correctly.
