Removal & Installation (Montero)

Remove EVAP emission ventilation solenoid. See EVAP EMISSION VENTILATION SOLENOID  under MOTORS, RELAYS & SOLENOIDS. Remove cap and vent hoses from ORVR vent valve module. See Figure. Remove vent pipe. Remove bracket from ORVR vent valve module. To install, reverse removal procedure.
