DTC Confirmation Procedure

WARNING: This page is about a different car, the 2003 Nissan Altima. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: For diagnostic procedure, see DIAGNOSTIC PROCEDURE .

For DTC confirmation procedure, see Fig 1 - Fig 2 .

Fig 1: Identifying DTC Confirmation Procedure For DTC P0452: EVAP Control System Pressure Sensor (With CONSULT-II)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Identifying DTC Confirmation Procedure For DTC P0452: EVAP Control System Pressure Sensor (With GST)

Courtesy of NISSAN MOTOR CO., U.S.A.
