>> C << Transaxle Mount Stopper Installation

WARNING: This page is about a different variant/trim than selected.

Tighten the self-locking nut so that the stabilizer bar mounting bolt protrudes as shown.

  1. Standard value: 22+/-1.5 mm (0.87+/-0.06 inch)
Fig 1: Installing Transaxle Mount Stopper
G01876073Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
