Circuit Operation
- While the vehicle is being driven, the PCM sends pulse signals (ranging from 0 to 12 volts) to the combination meter according to output signals from the output shaft speed sensor. The combination meter displays vehicle speed according to the pulse signals.
- If the vehicle speed signal becomes inoperative, the transaxle will not shift normally.
