>>B<< Shift Cable And Select Cable Assembly/Shift Cable Connection/Select Cable Connection

1. Set the transaxle side shift lever and the passenger compartment side shift lever to the neutral position.
2. For the transaxle side, the white and yellow paint marks on the shift and select cable ends should face the snap pins.
3. Move the shift lever to all positions and check that the operation is smooth.

Fig 1: Identifying Shift Cable Dimentions

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
