>> A << Steering Lock Cylinder Assembly/Steering Lock Bracket/Special Bolt Installation
WARNING: This page is about a different variant/trim than selected.
CAUTION:
The steering lock bracket and bolts must be replace with new ones when the steering lock is installed.
- When installing the steering lock cylinder and steering lock bracket to the column tube, temporarily install the steering lock in alignment with the column boss.
- After checking that the lock works properly, tighten the special bolts until the head twists off.
