Stoplight Switch

WARNING: This page is about a different variant/trim than selected.
  1. Disconnect the connector.
  2. Check for continuity between the terminals of the switch.
Fig 1: Identifying Connector Terminals
G00809833Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Fig 2: Identifying Continuity Specifications
G00809834Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
