<< A >> Spring Pin Removal

  1. Shift the 5th-reverse shift fork in the direction shown in the illustration.
  2. Using a pin punch, remove the spring pin from the shift fork and rail.
    Fig 1: Removing Spring Pin
    G00977685Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
