< 3.0L Engine (Vehicles With Variable Induction System) > Downshift Pattern

Fig 1: Identifying Vehicles With Variable Induction System, Downshift Pattern (3.0L Engine)
G02425293Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
