Diagnostic Trouble Code Chart

Fig 1: Diagnostic Trouble Code Inspection Chart
G02393323Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Check according to the inspection chart that is appropriate for the diagnostic trouble code.

DIAGNOSTIC TROUBLE CODE CHART

DIAGNOSTIC TROUBLE CODE NO.  INSPECTION ITEM
15  Auto-cruise control switch system
21  Cancel latch signal system
22  Stoplight switch system
23  Powertrain control module (PCM) and its related components
