General Specifications
General Specifications
| ITEMS | SPECIFICATIONS | |||
|---|---|---|---|---|
| 2.4L ENGINE | 3.8L ENGINE | |||
| 16-INCH WHEELS | 17-INCH WHEELS | |||
| Steering wheel | Type | 4-spoke type | 4-spoke type | 4-spoke type |
| Outside diameter mm (in) | 380 (14.9) | 380 (14.9) | 380 (14.9) | |
| Maximum number of turns | 2.94 | 2.94 | 2.76 | |
| Steering column | Column mechanism | Shock absorbing mechanism and Tilt steering mechanism | ||
| Power steering type | Integral type | Integral type | Integral type | |
| Oil pump | Type | vane pump | vane pump | vane pump |
| Basic discharge amount cm3 /rev. (cu in/rev) | 9.6 (0.59) | 9.6 (0.59) | 9.6 (0.59) | |
| Relief pressure MPa (psi) | 8.8 (1,422) | 9.8 (1,422) | 9.8 (1,422) | |
| Reservoir type | Separate type (plastic) | |||
| Pressure switch | Equipped | Equipped | Equipped | |
