INSPECTION PROCEDURE I-11: Headlight And Taillight: Daytime Running Light Function Does Not Work Normally. < Vehicles With Daytime Running Light Function >: Notes

Fig 1: Daytime Running Light Circuit Diagram
G02416721Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
