Disassembly And Assembly: Notes

CAUTION:
  • Be careful not to damage the ABS rotor, which is attached to the EBJ outer race during disassembly and reassembly.
  • Never disassemble the EBJ assembly except when replacing the EBJ boot.
    Fig 1: Removing EBJ Boot
    G02398619Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
NOTE: For EBJ boot removal and installation, refer to EBJ BOOT (RESIN BOOT) REPLACEMENT .
