Service Specifications
SERVICE SPECIFICATIONS
| ITEMS | STANDARD VALUE | LIMIT |
|---|---|---|
| Crankshaft journal outside diameter mm (in) | 64 (2.520) | - |
| Crankshaft pin outside diameter mm (in) | 55 (2.165) | - |
| Crankshaft journal oil clearance mm (in) | 0.02 - 0.04 (0.0008 - 0.0015) | 0.1(0.003) |
| Piston to cylinder clearance mm (in) | 0.02 - 0.04 (0.0008 - 0.0015) | - |
| Cylinder block flatness of gasket surface mm (in) | 0.05 (0.02) | 0.1 (0.003) |
| Cylinder block grinding limit of gasket surface mm (in) total resurfacing depth of both cylinder head and cylinder block | - | 0.2 (0.008) |
| Cylinder block overall height mm (in) | 227.9 - 228.1 (8.972 - 8.980) | - |
| Cylinder bore inside diameter mm (in) | 95.0 (3.740) | - |
| Cylindricity mm (in) | 0.01 (0.0003) | - |
