How to Read Data List
HOW TO READ DATA LISTRequired Special Tools
^ MB991958: Scan Tool (MUT-III) Sub Assembly)
^ MB991824: V.C.I.
^ MB991827: MUT-III USB Cable
^ MB991910: MUT-III Main Harness A
CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the LOCK (OFF) position before connecting or disconnecting scan tool MB991958,
1. Connect scan tool MB991958 to the data link connector.
2. Turn the ignition switch to the ON position.
3. Select Interactive Diagnosis from the start-up screen.
4. Select System select.
5. Choose ELC-A/T from the POWER TRAIN tab.
6. Select MITSUBISHI.
7. Select Data List.
8. Choose an appropriate item and select the OK button.
