< Vehicles With Center Bearing >: Notes
WARNING: This page is about a different variant/trim than selected.
CAUTION:
- For vehicles with ABS, be careful not to damage the ABS rotor, which is attached to the EBJ outer race during disassembly and assembly.
- Never disassemble the EBJ assembly except when replacing the EBJ boot.
NOTE:
- ETJ: Eco type Tripod Joint
- EBJ: Eight Ball fixed Joint
Required Special Tools:
- MB990810: Side Bearing Puller
- MB990890: Rear Suspension Bush Base
- MB990930: Installer Adapter
- MB990932: Installer Adapter
- MB990934: Installer Adapter
- MB990938: Bar (snap-in type)
- MB991172: Inner Shaft Installer Base
- MB991248: Inner Shaft Remover
- MB991561: Boot Band Crimping Tool
