Downshift Pattern < 4A/T >
Fig 1: Identifying Downshift Pattern (4A/T)
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
