>> A << Engine Starting Switch Assembly/Steering Lock Bolt Installation

CAUTION: The bolts must be replaced with new ones when the steering lock is installed.
  1. When installing the engine starting switch assembly to the steering column shaft assembly, temporarily install the engine starting switch assembly in alignment with the column boss.
  2. After checking that the lock works properly, tighten the steering lock bolts until the head is twisted off.
    Fig 1: Installing Engine Starting Switch Assembly/Steering Lock Bolt
    G04255530Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
