INSPECTION PROCEDURE I-9: Headlight and Taillight: Headlight automatic shutdown function does not work normally.: Notes

NOTE: This troubleshooting procedure requires the use of scan tool MB991958 and SWS monitor kit MB991813. For details on how to use the SWS monitor, refer to "HOW TO USE SWS MONITOR  ."

Fig 1: Identifying Headlight Automatic Shut Down Circuit

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
