<< B >> Piston Seal Removal

WARNING: This page is about a different variant/trim than selected.
CAUTION: To prevent damage to inner cylinder, do not use a flat-tipped screwdriver or other tool.
  1. Remove the piston seal with finger tip.
  2. Clean the piston surface and cylinder inner face with alcohol or specified brake fluid.
    Fig 1: Removing Front Piston Seals
    G09650803Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

    Brake fluid: DOT3 or DOT4
