Removal And Installation: Notes
WARNING: This page is about a different variant/trim than selected.
CAUTION:
- Before removing the steering wheel assembly and driver's air bag module/knee air bag module, always refer to SERVICE PRECAUTIONS and DRIVER'S AIR BAG MODULE AND CLOCK SPRING or KNEE AIR BAG MODULE .)
- After installation, perform a calibration for the ASC-ECU to learn the steering wheel sensor neutral point. (Refer to STEERING WHEEL SENSOR CALIBRATION .)
