Hub Removal

CAUTION: When the hub has been removed, always replace the wheel bearing with a new part because wheel bearing frictional surface will be damaged when removing the hub.

Use the following special tools to pull out the front wheel hub assembly from the knuckle.

Front hub remover and installer (MB991017)
NOTE: Except spacer (MB991019).
Knuckle arm bridge (MB991355)
Knuckle Arm Bridge attachment (MB992250)
Front hub remover and installer spacer (MB992867)

Fig 1: Pulling Out Front Wheel Hub Assembly From Knuckle Using Suitable Tool
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
