Periodic Reminder Schedule Set

The service reminder schedule can be changed.

NOTE: In addition to the operation of the scan tool (M.U.T.-III), the schedule can be changed by operating the meter information switch on the combination meter. Refer to HOW TO SET BY SPECIAL OPERATION OF SWITCH .

Fig 1: Screen Display - Service Reminder (4014308A6)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

On the "Service Reminder" screen, select "5 Periodic reminder schedule set."
NOTE: The screen indicates that the current schedule (No. 7 in the data list) has been set to "Normal."

Fig 2: Screen Display - Service Reminder (4014308A4)
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Set the schedule to be changed from "Set value."
Press the "OK" button.

Fig 3: Screen Display - Service Reminder (4014308A4)
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
The schedule is changed.
NOTE: The screen indicates that the current schedule (No. 7 in the data list) has been changed to "NAS 10."
