>>C<< Shift Lever Boot Installation

  1. Shift lever boot is hooked and attached to the slot on the control cover.
  2. Install the shift lever boot so that the embossed mark is in the direction shown in the figure.
Fig 1: Shift Lever Boot Mating Marks
G11278186Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
