Removal And Installation: Notes
WARNING: This page is about a different variant/trim than selected.
CAUTION:
- When removing and installing the transaxle assembly, be careful not to drop the torque converter. In addition, do not remove the torque converter.
- When the transaxle assembly is replaced, initialize the CVT learned value (Refer to INITIALIZATION PROCEDURE FOR CVT LEARNED VALUE ).
Pre-removal Operation
- Under Cover Front Removal (Refer to UNDER COVER ).
- Transmission Fluid Draining (Refer to TRANSMISSION FLUID REPLACEMENT ).
- Engine Coolant Draining (Refer to ENGINE COOLANT REPLACEMENT ).
- Starter Motor Assembly Removal (Refer to STARTER MOTOR ASSEMBLY ).
- Exhaust Manifold Removal (Refer to EXHAUST MANIFOLD .)
- Drive Shaft Removal (Refer to DRIVE SHAFT ASSEMBLY .)
- Air Cleaner Assembly Removal (Refer to AIR CLEANER .
- Battery and Battery Tray Removal (Refer to BATTERY .
Post-installation Operation
- Battery and Battery Tray Installation (Refer to BATTERY .
- Air Cleaner Assembly Installation (Refer to AIR CLEANER .
- Drive Shaft Installation (Refer to DRIVE SHAFT ASSEMBLY .)
- Exhaust Manifold Installation (Refer to EXHAUST MANIFOLD .)
- Starter Motor Assembly Installation (Refer to STARTER MOTOR ASSEMBLY ).
- Engine Coolant Refilling (Refer to ENGINE COOLANT REPLACEMENT ).
- Transmission Fluid Refilling (Refer to TRANSMISSION FLUID REPLACEMENT ).
- Under Cover Front Installation (Refer to UNDER COVER ).
Required Special Tools:
- MB991895: Engine Hanger
- MB991928: Engine Hanger
- Joint x 2 (50) (MB991929)
- Foot x 4 (standard) (MB991932)
- MB992906: Engine hanger attachment
