Removal And Installation: Notes
Pre-removal and Post-installation Operation
- Removal and Installation of Front Pillar Trim, Upper center Pillar Trim, Rear Pillar Trim. Refer to TRIMS .
- Removal and Installation of Rear Seatbelt Outer Assembly (RH or LH). Refer to REAR SEAT BELT .
- Removal and Installation of Dome Light Assembly. Refer to DOME LIGHT .
- Removal and Installation of Passenger's Air Bag Cut OFF Indicator Light Assembly. Refer to PASSENGER'S AIR BAG ON/OFF INDICATOR LIGHT .
