Removal And Installation <Rear>: Notes

CAUTION: The vehicle speed detection encoder collects any metallic particle easily, because it is magnetized. Make sure that the encoder should not collect any metallic particle. Check that there is not any trouble prior to reassembling it.

<FWD>

Pre-removal and post-installation operation

Cargo floor box removal and installation (Refer to Trims, INTERIOR TRIM ).

Fig 1: Removing/Installing Front Wheel Speed Sensor Components Location With Torque Specification (FWD)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

<AWD>

Pre-removal and post-installation operation

Cargo floor box removal and installation (Refer to Trims, INTERIOR TRIM ).

Fig 2: Removing/Installing Front Wheel Speed Sensor Components Location With Torque Specification (AWD)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
