Switches And Indicators

G16071104Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
(1) ASCD indicator
(2) CANCEL switch
(3) RES+ switch
(4) SET- switch
(5) MAIN switch
(A) On the combination meter
(B) On the steering wheel
