Separation Work

WARNING: This page is about a different car, the 2004 Nissan Murano and 2003 Nissan Murano. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install engine slingers into rear of left bank cylinder head and front of right bank cylinder head.
    Fig 1: View Of Front Engine Slinger
    G00908578Courtesy of NISSAN MOTOR CO., U.S.A.
    Fig 2: View Of Rear Engine Slinger
    G00908579Courtesy of NISSAN MOTOR CO., U.S.A.
  2. Remove power steering oil pump, power steering piping and power steering bracket from engine, transaxle and transfer (AWD models) assembly. Refer to HYDRAULIC LINE .
  3. Remove starter motor. For 2003 models, see STARTER . For 2004 Models, see STARTER .
  4. Disconnect harness connector of front engine mounting insulator and rear engine mounting insulator.
  5. Lift with hoist and separate engine, transaxle and transfer (AWD models) assembly from suspension member.
    CAUTION:
    • Before and during this lifting, always check if any harnesses are left connected.
    • Avoid damage to and oil/grease smearing or spills onto engine mounting insulator.
  6. Separate engine, transaxle and transfer (AWD models) assembly. Refer to TRANSAXLE ASSEMBLY .
