Door Lock Function Malfunction

WARNING: This page is about a different car, the 2005 Infiniti FX45 and 2005 Infiniti FX35. However, it is still accessible from the selected car via links, so may be relevant.

Before conducting the diagnosis in the following table, check all power door lock system function. Refer to "POWER DOOR LOCK SYSTEM ".

Fig 1: Trouble Diagnosis Symptom Chart - Engine Start Function Malfunction
G02362289Courtesy of NISSAN MOTOR CO., U.S.A.
