TCM Inspection Table
WARNING: This page is about a different car, the 2006 Nissan Xterra. However, it is still accessible from the selected car via links, so may be relevant.
Data are reference value and are measured between each terminal and ground.
CONNECTOR TERMINAL VOLTAGE REFERENCE
| Terminal No. | Wire color | Item | Condition | Data (Approx.) | |
|---|---|---|---|---|---|
| 1 | R/B | Power supply (Memory back up) |
Always | Battery voltage | |
| 2 | R/B | Power supply (Memory back up) |
Always | Battery voltage | |
| 3 | L | CAN-H | - | - | |
| 4 | V | K-line (CONSULT-II signal) | The terminal is connected to the data link connector for CONSULT-II. | - | |
| 5 | B | Ground | Always | 0V | |
| 6 | W/G | Power supply | - | Battery voltage | |
| - | 0V | ||||
| 7 | LG | Back up lamp relay | Selector lever in "R" position. | 0V | |
| Selector lever in other positions. | Battery voltage | ||||
| 8 | P | CAN-L | - | - | |
| 9 | R | Starter relay | Selector lever in "N", "P" positions. | Battery voltage | |
| Selector lever in other positions. | 0V | ||||
| 10 | B | Ground | Always | 0V | |
