Map Display

WARNING: This page is about a different car, the 2005 Infiniti FX45 and 2005 Infiniti FX35. However, it is still accessible from the selected car via links, so may be relevant.

Function of each icon is as follows:

Azimuth indication
Position marker
- The tip of the arrow shows the current location. The shaft of the arrow indicates the direction in which the vehicle is traveling.
GPS reception signal (indicates current reception conditions.)
Distance display (shows the distance in a reduced scale.)

Fig 1: Identifying Map Display
Courtesy of NISSAN MOTOR CO., U.S.A.
