Removal and Installation: Removal

WARNING: This page is about a different car, the 2006 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION:
  • Do not attempt to repair or replace damaged direct-connect SRS component connectors. If a driver air bag direct-connect harness connector is damaged, the spiral cable must be replaced.
  • Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 minutes.
  • When servicing the SRS, do not work from directly in front of air bag module.
  1. Disconnect the negative and positive battery cables, then wait at least 3 minutes.
  2. Locate retaining clip access hole and insert suitable 4mm - 6mm blunt tool.
    NOTE: Do not use sharp edged objects such as screwdrivers to release driver air bag module from steering wheel, SRS components may be unintentionally damaged.
    Fig 1: Disconnecting Negative And Positive Battery Cables
    G04175718Courtesy of NISSAN MOTOR CO., U.S.A.
  3. Press upward (toward center of steering wheel) on retaining clip until driver air bag module is released from steering wheel.
  4. Lift the driver air bag module from the steering wheel.
  5. Disconnect the driver air bag module and horn connectors, then remove the driver air bag module.
CAUTION:
  • When servicing the SRS, do not work from directly in front of air bag module.
  • Always place air bag module with pad side facing upward.
  • Do not insert any foreign objects (screwdriver, etc.) into air bag module or connectors.
  • Do not disassemble air bag module.
  • Do not expose the air bag module to temperatures exceeding 90°C (194°F).
    Fig 2: Lifting Driver Air Bag Module From Steering Wheel
    G04175719Courtesy of NISSAN MOTOR CO., U.S.A.
  • Replace the air bag module if it has been dropped or sustained an impact.
  • Do not allow oil, grease or water to come in contact with the air bag module.
Fig 3: Precaution For Handling Air Bag Module
G04076880Courtesy of NISSAN MOTOR CO., U.S.A.
