With Consult-II

  1. Check the coolant level in the reservoir tank and radiator. Allow engine to cool before checking coolant level.

    If the coolant level in the reservoir tank and/or radiator is below the proper range, skip the following steps and go to DIAGNOSTIC PROCEDURE .

  2. Confirm whether customer filled the coolant or not. If customer filled the coolant, skip the following steps and go to DIAGNOSTIC PROCEDURE .
  3. Turn ignition switch ON.
    Fig 1: Checking Coolant Level In Reservoir Tank
    G02443920Courtesy of NISSAN MOTOR CO., U.S.A.
  4. Perform "COOLING FAN" in "ACTIVE TEST" mode with CONSULT-II.
  5. If the results are NG, go to DIAGNOSTIC PROCEDURE .
    Fig 2: CONSULT-II Display - "ACTIVE TEST" Mode
    G02443921Courtesy of NISSAN MOTOR CO., U.S.A.
