Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Fig 1: Special Service Tools Description Chart (1 Of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Special Service Tools Description Chart (2 Of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.
