Component Structure: Notes

WARNING: This page is about a different car, the 2005 Nissan Altima. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Of Front Door Window Component Structure

Courtesy of NISSAN MOTOR CO., U.S.A.

Inspection and Adjustment

Remove the front door finisher. Refer to "DOOR FINISHER ".
Remove the front door window and front door module assembly. Refer to "FRONT DOOR GLASS AND REGULATOR ".
