Component Function Check

  1. CHECK FUEL PUMP FUNCTION
    1. Turn ignition switch ON.
    2. Pinch fuel feed hose (2) with two fingers.
      Fig 1: Pinching Fuel Feed Hose
      G05688492Courtesy of NISSAN MOTOR CO., U.S.A.

      Fuel pressure pulsation should be felt on the fuel feed hose for 1 second after ignition switch is turned ON.

    Is the inspection result normal?

    YES : INSPECTION END

    NO : "DIAGNOSIS PROCEDURE ".
