IGNITION TIMING : Special Repair Requirement

CHECK IGNITION TIMING
1. Attach timing light (A) to No. 1 ignition coil wire as shown.
  - = : Vehicle front

    Fig 1: Attaching Timing Light To No. 1 Ignition Coil Wire
2. Check ignition timing.
  - Timing indicator (1)
    INSPECTION END

    Fig 2: Identifying Timing Indicator
