Removal and Installation: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Disconnect the 12-volt battery negative terminal.
  2. Remove the cluster lid D. Refer to "REMOVAL AND INSTALLATION ".
  3. Remove the cluster lid D screws (A), then remove the audio unit screws (B) and the audio unit (1).
Fig 1: Identifying Audio Unit Screws And Audio Unit
G04889838Courtesy of NISSAN MOTOR CO., U.S.A.
