Component Inspection

CHECK POWER WINDOW RELAY

Check power window relay.

Fig 1: Checking Continuity Between Blower Relay Terminal 3 And 5

Courtesy of NISSAN NORTH AMERICA, INC.

Terminal		Condition	Continuity
Power window relay		Condition	Continuity
3	5	12V direct current supply between terminals 1 and 2.	Yes
3	5	No current supply	No

Is the inspection result normal?

YES

Inspection End.

Replace power window relay.
