Exploded View With Torque Specifications
Courtesy of NISSAN NORTH AMERICA, INC.
1.
Opera window glass
2.
Adhesive
3.
Front pillar finisher
4.
Body side outer
5.
Body primer
6.
Primer
7.
Front fender
E.
12.0 mm (0.47 in)
F.
11.0 mm (0.43 in)
G.
20.0 mm (0.79 in)
Clip
Pawl
Courtesy of NISSAN NORTH AMERICA, INC.
