Component Locations

COMPONENT LOCATIONS

Component	Location
Left/Right Mirror	On Respective Door. See Fig 1
Switches	On Center Console. See Figure

Fig 1: Identifying Motor & Gear Assembly Components

Courtesy of CHRYSLER CORP.
