Installation Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.

Install the bulb to the backup lamp socket.
Rotate the socket clockwise to engage the locking tabs.
Install the backup lamp socket to the backup lamp assembly.
Install the inner tail lamp. Refer to TAIL LAMP REPLACEMENT .

Fig 1: Installing Bulb To Backup Lamp Socket
Courtesy of GENERAL MOTORS CORP.
